Discover the Gigabyte H610M H V2 DDR4 LGA1700 mATX Motherboard, tailored for optimizing your computing experience. Equipped with a 6+1+1 Hybrid Phases Digital VRM Design, this motherboard ensures stable power delivery to your system's components. Experience the future of connectivity with PCIe 4.0, offering faster data transfer speeds. With a Gen3 x4 M.2 slot, it provides ample space for high-speed SSDs. Built to last, it features Anti-Sulfur Resistors and Smart Fan 6 for enhanced durability and cooling efficiency.

• Supports Intel® Core™ 14th/ 13th /12th processors

  · Dual Channel Non-ECC Unbuffered DDR4, 2 DIMMs

  · 6+1+1 Hybrid Digital VRM Design

  · GbE LAN with Bandwidth Management

  · NVMe PCIe 3.0 x4 M.2

  H610M S2H V2 DDR4 (rev. 1.0)

  Intel® H610 Motherboard with 6+1+1 Hybrid Phases Digital VRM Design, PCIe 4.0* Design, Gen3 x4 M.2, DisplayPort / HDMI / DVI-D/ D-Sub Ports for Multiple Display, Anti-Sulfur Resistor,  Smart Fan 6.

  - DisplayPort / HDMI / DVI-D / D-Sub Ports for Multiple Display

  - High Quality Audio Capacitors and Audio Noise Guard

  - Smart Fan 6 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP

  - GIGABYTE APP Center, Simple and Easy Use

  - Anti-Sulfur Resistors Design.



  Gigabyte Ultra Durable



  ---





  Overview



  ---





  Power - 6+1+1 Phases Hybrid Power Design

  Cleaner and more efficient power delivery to the CPU with better thermal performance ensures stability under high CPU frequencies and heavy loading.

  - 6+1+1 Phases Low RDS(on) MOSFETs

  - Solid capacitors to improve transient response and minimise oscillation.

  - 8-pin Solid Pin CPU Power Connector.



  ---



  PERFORMANCE



  PCIe 4.0 Design

  Single 32GB Support

  Faster Speed

  32GB Capacity

  Multi-Tasking

  RAM Intensive

  Quick Response

  Lower Usage

  The maximum memory capacity on the H610 motherboard is 64 GB. After Intel updated the memory reference code, a single slot can support up to 32GB. Therefore, with 2 DIMMs per channel, the total memory capacity is 64GB, which was only available on high-end desktop (HEDT) platforms. For users who always run out of memory capacity, there is more bandwidth now for memory-intensive applications such as rendering and video editing.



  SMART FAN 6

  The maximum memory capacity on the H610 motherboard is 64 GB. After Intel updated the memory reference code, a single slot can support up to 32GB. Therefore, with 2 DIMM per channel, the total memory capacity is 64GB, which was only available on High-End Desktop (HEDT) platforms. For users who always run out of memory capacity, there is more bandwidth now for memory-intensive applications such as rendering and video editing.

  Cooling Features

  High Current Support - Each fan headers support PWM and DC fan and Water cooling Pump, and up to 24W (12V x 2A) with Over-Current Protection

  Precision Control - Up to 7 temperature/fan speed control points for precise fan curve

  Dual Curve Mode - Slope/Stair dual mode for different user scenarios

  Fan Stop - The fan can stop entirely below the user's specified temperature point



  Hybrid Cores Optimisation

  With new Intel Hybrid technology, GIGABYTE exclusively creates two new "CPU Upgrade" in BIOS profiles to meet different users’ scenarios by adjusting P-Core and E-Core activation and voltage policy.



  ---



  CONNECTIVITY



  GbE LAN with Bandwidth Management

  GbE LAN features a network bandwidth management application that helps to improve network latency and maintain low ping times to deliver better responsiveness in crowded LAN environments.



  NVMe PCIe Gen3 x4 M.2 Connector

  GIGABYTE Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximise their system's potential.



  High-Definition Digital Outputs - 4 Digital Outputs

  Enjoy true HD display capability using today's HD displays and TVs' most commonly integrated digital TV technologies.

  * Maximum support of 3 independent displays at one time.



  High-End Audio Capacitors

  GIGABYTE motherboards use high-end audio capacitors. These capacitors help deliver high-resolution and high-fidelity audio, providing gamers with the most realistic sound effects.

  Audio Noise Guard

  GIGABYTE motherboards feature an audio noise guard that essentially separates the board’s sensitive analog audio components from potential noise pollution at the PCB level.

  *Photo for reference only.



  ---



  ULTRA DURABLE



  Solid Pin Power Connectors

  H610 motherboards feature solid-plated ATX 12V 8pin power connectors to offer a stable power supply during CPU overloading.

  Solid Pin Power connector advantages

  - Larger contact area for electricity

  - More metal quantity to sustain higher power and generated heat

  - Ultra-durable and longer lifespan.



  START SULFURISATION PROTECTION

  Sulphur compounds in the air can penetrate tiny onboard resistors, creating a chemical change and causing them to open or short. If either of these occurs, the motherboard will fail to function. By equipping resistors with an Anti-Sulfur Design, GIGABYTE gives Ultra-Durable Motherboards a whole new meaning.



  ---



  SOFTWARE



  BIOS

  During initial setup, the BIOS is essential for users to allow for the most optimal settings. With a new GUI and easier-to-use functionalities, GIGABYTE has been able to reinvent the BIOS to give users a better experience while setting up their new system.

  * Photos are for reference only. Product features may vary by model.



  APP CENTER

  GIGABYTE APP CENTER is a useful portal for all GIGABYTE MB utilities and drivers. You can choose any utility you want to install from APP CENTER and keep updated with the latest versions.



  EasyTune

  GIGABYTE's EasyTune is a simple, easyGIGABYTE'sterface for fine-tuning system settings or adjusting system and memory clocks and voltages in a Windows environment.



  System Information Viewer

  GIGABYTE System Information Viewer is a central location that gives you access to your current system status. Monitor components such as the clocks and processor, set your preferred fan speed profile, create alerts when temperatures get too high or record your system's behaviour; these are the possibilities of the System Information Viewer.



  ---





  SKU # AC75019 | Model # H610M S2H V2 DDR4

This 8GB (1x 8GB) DDR4 2133 MT/s Dual rank, x8 configuration RAM module from Hynix is for use in DDR4 compatible systems and operates at 2133 MT/s with an overall transfer rate of PC4-17000.

This RAM module also operates at a standard voltage of 1.2V and is designed to allow you to run more applications simultaneously, switch between them faster, and provide a smoother computing experience.
