AMD Ryzen 7 5700 8C/16T 3.70GHz / 4.60GHz AM4
Regular price $279.00 Save $-279.00MD Ryzen 5 5500 (Base: 3.60GHz, Boost: 4.20GHz / 19MB Cache / AM4 / 6 Core / 65 Watt
Product Specs
|
GENERAL SPECIFICATIONS |
||
|
Product Family |
AMD Ryzen™ Processors |
|
|
Product Line |
AMD Ryzen™ 7 Desktop Processors |
|
|
Number of CPU Cores |
8 |
|
|
Number of Threads |
16 |
|
|
Max. Boost Clock |
Up to 4.6GHz |
|
|
Base Clock |
3.7GHz |
|
|
L1 Cache |
512KB |
|
|
L2 Cache |
4MB |
|
|
L3 Cache |
16MB |
|
|
Default TDP |
65W |
|
|
AMD Configurable TDP (cTDP) |
45-65W |
|
|
Processor Technology for CPU Cores |
TSMC 7nm FinFET |
|
|
CPU Compute Die (CCD) Size |
180mm² |
|
|
Package Die Count |
1 |
|
|
Unlocked for Overclocking |
Yes |
|
|
CPU Socket |
AM4 |
|
|
Socket Count |
1P |
|
|
Supporting Chipsets |
X570 |
|
|
CPU Boost Technology |
Precision Boost 2 |
|
|
Instruction Set |
x86-64 |
|
|
Supported Extensions |
AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
|
|
Thermal Solution (PIB) |
AMD Wraith Stealth |
|
|
Max. Operating Temperature (Tjmax) |
95°C |
|
|
Launch Date |
4/4/2022 |
|
|
OS Support |
Windows 10 - 64-Bit Edition |
|
|
CONNECTIVITY |
||
|
USB Type-C® Support |
Yes |
|
|
Native USB 4 (40Gbps) Ports |
0 |
|
|
Native USB 3.2 Gen 2 (10Gbps) Ports |
4 |
|
|
Native USB 3.2 Gen 1 (5Gbps) Ports |
0 |
|
|
Native USB 2.0 (480Mbps) Ports |
0 |
|
|
Native SATA Ports |
2 |
|
|
PCI Express® Version |
PCIe 3.0 |
|
|
Native PCIe® Lanes (Total/Usable) |
24 / 20 |
|
|
Additional Usable PCIe Lanes from Motherboard |
AMD X570 16x Gen 3 |
|
|
NVMe Support |
Boot, RAID0, RAID1, RAID10 |
|
|
System Memory Type |
DDR4 |
|
|
Memory Channels |
2 |
|
|
System Memory Subtype |
UDIMM |
|
|
System Memory Specification |
Up to 3200MT/s |
|
|
Max Memory Speed |
2x1R |
DDR4-3200 DDR4-3200 DDR4-2933 DDR4-2667 |
|
ECC Support |
No |
|
|
GRAPHICS CAPABILITIES |
||
|
Integrated Graphics |
No |
|
|
Graphics Model |
Discrete Graphics Card Required |
|
|
KEY FEATURES |
||
|
Supported Technologies |
AMD StoreMI Technology |
|
