GIGABYTE B850M FORCE Wi-Fi 6E V2 AM5 mATX Motherboard | In-Store Only
Regular price $199.00In-Store Only – Not Available Online
Special in-store pricing for this product is available exclusively at our Maroubra Store (NSW).
The Gigabyte B850M FORCE WIFI6E V2 is a compact Micro-ATX AM5 motherboard built for modern AMD Ryzen processors, featuring the AMD B850 chipset, dual-channel DDR5 memory support, and integrated Wi-Fi 6E connectivity.
Designed for fast and reliable performance, it includes a PCIe x16 expansion slot, ultra-fast storage support, 4x SATA 6Gb/s ports, USB Type-C connectivity, HDMI and DisplayPort outputs, plus Gigabyte features such as EZ-Latch, WIFI EZ-Plug and an easy-to-use BIOS interface.
Ideal for powerful gaming, workstation and everyday AM5 PC builds in a compact Micro-ATX format.
Specifications
| Component / Category | Specification Details |
| CPU | AMD Socket AM5, support for: |
| - AMD Ryzen™ 9000 Series Processors | |
| - AMD Ryzen™ 8000 Series Processors | |
| - AMD Ryzen™ 7000 Series Processors | |
| (Go to GIGABYTE's website for the latest CPU support list.) | |
| Chipset | AMD B850 |
| Memory | Support for DDR5 9600(OC)/ 9200(OC)/ 8800(OC)/ 8600(OC)/ 8400(OC)/ 8200(OC)/ 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6666(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800/ 4400 MT/s memory modules |
| 2 x DDR5 DIMM sockets supporting up to 128 GB (64 GB single DIMM capacity) of system memory | |
| Dual channel memory architecture | |
| Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules | |
| Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules | |
| (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" on GIGABYTE's website for more information.) | |
| Onboard Graphics | Integrated Graphics Processor with AMD Radeon™ Graphics support: |
| - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz (HDMI 2.1 version, HDCP 2.3, HDR, native HDMI 2.1 TMDS compatible) | |
| - 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz (DisplayPort 1.4 version) | |
| (Graphics specifications may vary depending on CPU support.) | |
| Audio | Realtek® Audio CODEC |
| High Definition Audio | |
| 2/4/5.1/7.1-channel | |
| * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. | |
| LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication module | MediaTek Wi-Fi 6E MT7902 |
| - WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands | |
| - BLUETOOTH 5.3 | |
| - Support for 11ax 160MHz wireless standard | |
| (Actual data rate may vary depending on environment and equipment.) | |
| * Bluetooth version may change with updates. See the Wi-Fi chip vendor's website for details. | |
| Expansion Slots | 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: |
| - AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x16 mode | |
| - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode | |
| - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode | |
| * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. | |
| Chipset: | |
| - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4) | |
| Storage Interface | 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs: |
| - AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs | |
| - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs | |
| - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs | |
| 1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs: | |
| - AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs | |
| - AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs | |
| - AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs | |
| 1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280 PCIe 4.0 x2 SSDs | |
| 4 x SATA 6Gb/s connectors | |
| RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices (* RAID 5 is only available on AMD Ryzen™ 9000 Series Processors) | |
| RAID 0, RAID 1, and RAID 10 support for SATA storage devices | |
| USB | CPU: |
| - 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 1 support | |
| - 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel | |
| - 1 x USB 2.0/1.1 port on the back panel | |
| Chipset: | |
| - 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header | |
| - 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) | |
| - 5 x USB 2.0/1.1 ports (1 port on the back panel, 4 ports available through the internal USB headers) | |
| Internal I/O Connectors | 1 x 24-pin ATX main power connector |
| 1 x 8-pin ATX 12V power connector | |
| 1 x CPU fan header | |
| 1 x CPU fan/water cooling pump header | |
| 1 x system fan header | |
| 1 x system fan/water cooling pump header | |
| 3 x addressable RGB Gen2 LED strip headers | |
| 1 x RGB LED strip header | |
| 3 x M.2 Socket 3 connectors | |
| 4 x SATA 6Gb/s connectors | |
| 1 x front panel header | |
| 1 x front panel audio header | |
| 1 x USB Type-C® header, with USB 3.2 Gen 1 support | |
| 1 x USB 3.2 Gen 1 header | |
| 2 x USB 2.0/1.1 headers | |
| 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI V2 module only) | |
| 1 x reset jumper | |
| 1 x Clear CMOS jumper | |
| 1 x Q-Flash Plus button | |
| Back Panel Connectors | 1 x HDMI port (Note: Actual support may vary by CPU) |
| 1 x DisplayPort (Note: Actual support may vary by CPU) | |
| 1 x PS/2 keyboard/mouse port | |
| 1 x USB Type-C® port, with USB 3.2 Gen 1 support | |
| 2 x USB 3.2 Gen 1 ports | |
| 1 x USB 3.2 Gen 2 Type-A port (red) | |
| 2 x USB 2.0/1.1 ports | |
| 1 x RJ-45 port | |
| 2 x antenna connectors (1T1R) | |
| 3 x audio jacks | |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage detection |
| Temperature detection | |
| Fan speed detection | |
| Water cooling flow rate detection | |
| Fan fail warning | |
| Fan speed control (* Speed control support depends on installed fan/pump) | |
| BIOS | 1 x 256 Mbit flash |
| Use of licensed AMI UEFI BIOS | |
| PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | |
| Unique Features | Support for GIGABYTE Control Center (GCC) (* Applications/functions vary by model and specs) |
| Support for Q-Flash | |
| Support for Q-Flash Plus | |
| Support for Smart Backup | |
| Bundled Software | Norton® Internet Security (OEM version) |
| Operating System | Support for Windows 11 64-bit |
| Support for Windows 10 64-bit | |
| Form Factor | Micro ATX Form Factor; 24.4cm x 24.4cm |
